HP231 Automatic Brushless Contactless Car Wash Machine for America/Latin America

HP231 Automatic Brushless Contactless Car Wash Machine for America/Latin America

Place of Origin:

Shandong, China

Brand Name:

RISENSE

Model Number:

HP231

Contact Us
Request A Quote
HP231 Automatic Brushless Contactless Car Wash Machine for America/Latin America HP231 Automatic Brushless Contactless Car Wash Machine for America/Latin America HP231 Automatic Brushless Contactless Car Wash Machine for America/Latin America HP231 Automatic Brushless Contactless Car Wash Machine for America/Latin America HP231 Automatic Brushless Contactless Car Wash Machine for America/Latin America HP231 Automatic Brushless Contactless Car Wash Machine for America/Latin America
Product Details
Size:
7600*3315*3150mm
Material:
Hot-dip Galvanized Steel
Warranty:
Lifetime Technique Support Service
Output Power:
Total 42Kw, Max.20kw When Running
Design Style:
New China-Chic
Machine Dimension:
L*W*H=7600*3310*3150mm
Assembling Range:
L*W*H=7600*3500*3300
Voltage Requirement:
3 Phase 380V 50HZ
Pump Pressure:
6-8 Mpa
Air Requirement:
0.5-0.7MPa
Car Wash Size:
L5300mm*W2200mm*H2050mm
Car Wash Time:
Fast Wash 3min/Car; Fin Wash 5min/Car
Wiping-free Spraying System:
One Group
Bright Wax Spray System:
One Group
Fault Self-test:
Include
Payment & Shipping Terms
Minimum Order Quantity
1 PC
Price
$15,000.00/sets 1-4 sets
Packaging Details
Packed in 20 GP container
Supply Ability
1200 Set/Sets per Year automatic car wash
RELATED PRODUCTS
Good price Automatic Touchless Car Vehicle Detail Wash Machine Equipment Station Hp-261 by Risense online Video

Automatic Touchless Car Vehicle Detail Wash Machine Equipment Station Hp-261 by Risense

Get Best Price
Good price Risense HP-231 Touchless Car Wash Machine L*W*H 7600*3315*3100 for Quick Installation online Video

Risense HP-231 Touchless Car Wash Machine L*W*H 7600*3315*3100 for Quick Installation

Get Best Price
Good price Touchless Car Wash Machine with Payment Term of 30% TT Pre Payment 70% Balance online Video

Touchless Car Wash Machine with Payment Term of 30% TT Pre Payment 70% Balance

Get Best Price
Good price Hot dip galvanizing steel Risense smart model with 120 bar high pressure Robot touchless car wash machine online Video

Hot dip galvanizing steel Risense smart model with 120 bar high pressure Robot touchless car wash machine

Get Best Price
Contact Us
Contact Now
Product Description
Product Overview

Best sell in South-east Asia/Latin America Single Arm Touchless Car Wash HP-231

The single arm touchless car wash machine is the independently researched and developed full automatic intelligent touch free car wash machine integrated with the washing and maintaining together. It has the following functions:
1.chassis washing---2.car pre-washing---3.wipe-free shampoo spraying---4.high pressure water washing---5.wire drawing rich foam shampoo washing---6.high pressure water washing---7.bright wax coating---8.strong air drying
FEATURES AT A GLANCE
✿ High pressure water of 120bar

✿ Chassis washing function

✿ Pre-soak chemical function

✿ wire drawing rich foam shampoo washing

✿ Wax rinse

✿Dryer function

✿ LCD screen, parking positioning voice prompt

HP231 Automatic Brushless Contactless Car Wash Machine for America/Latin America 0
HP231 Automatic Brushless Contactless Car Wash Machine for America/Latin America 1

1. Chassis jet and side jet wash

High pressure water can be 90 Bar, could wash
and remove the dirty and mud from the tires, wheels, bottom, both bottom sides of vehicles.

Two sets side jet nozzle, to wash tires, wheels and both sides of vehicles +​​​​​​​One set bottom jet nozzle to wash the car's under chassis.
HP231 Automatic Brushless Contactless Car Wash Machine for America/Latin America 2


2.High pressure water rinsing

High pressure water 360 degree pre-washing , rinse and loosen the dust and stains of car surface, 27 seconds one circle.
HP231 Automatic Brushless Contactless Car Wash Machine for America/Latin America 3


3. Spraying of ACTIVE LIQUID


Second circle, spraying of the ACTIVE LIQUID, could effectively loosen the dust and mud.
HP231 Automatic Brushless Contactless Car Wash Machine for America/Latin America 4
4.1 360 degree--High pressure water rinsing
HP231 Automatic Brushless Contactless Car Wash Machine for America/Latin America 5
4.2 360 degree--High pressure water rinsing
HP231 Automatic Brushless Contactless Car Wash Machine for America/Latin America 6

5.1 Foam spraying

High-foaming glazing and curing car washing liquid, dense foam can effectively remove body dust, dirt etc.
HP231 Automatic Brushless Contactless Car Wash Machine for America/Latin America 7

5.2 Foam spraying


HP231 Automatic Brushless Contactless Car Wash Machine for America/Latin America 8

5.3 Foam spraying


HP231 Automatic Brushless Contactless Car Wash Machine for America/Latin America 9

6.1 High pressure water rinse

HP231 Automatic Brushless Contactless Car Wash Machine for America/Latin America 10

6.2 High pressure water rinse

HP231 Automatic Brushless Contactless Car Wash Machine for America/Latin America 11

6.3 High pressure water rinse

HP231 Automatic Brushless Contactless Car Wash Machine for America/Latin America 12

7.1 Water wax coating

The coating can directly improve the brightness
of the body and protect the paint
HP231 Automatic Brushless Contactless Car Wash Machine for America/Latin America 13

7.2 Water wax coating

(Coated water wax can form a layer of polymer curing film on the surface of the car paint, which directly improves the brightness of the car body and protects the car paint).
HP231 Automatic Brushless Contactless Car Wash Machine for America/Latin America 14

8.1 Strong freestanding Air Dryer

External powerful fixed 4 kits of 5.5kw turbine multi-blade high wind pressure air drying system.


HP231 Automatic Brushless Contactless Car Wash Machine for America/Latin America 15

8.2 Strong freestanding Air Dryer

The principle of aerodynamics + international leading technology, forming a wind curtain wall effect, the drying effect can reach more than 90%.
PRODUCT SPECIFICATIONS
Machine dimension
L7600*W3310*H3150
Mains voltage
3 phase AC380V/50HZ
Assembling size
L7600*W3500*H3300
Total power
total 42kw with dryer,
 22kw when washing
Operate room
L3500*W1800*H2300
Pomp pressure
6-8 Mpa
Available size for car
L5300*W2200*H2050
Air pressure
0.5-0.7Mpa
Fine wash
5 minutes
Water/electricity consumption
165 L/Car, 0.75 kw/Car
Regular wash time
3 minutes
Shampoo/Wax consumption
12-35ml/Car,
12-35ml/Car
Vehicle type
Car/Minibus/SUV/Coach within 7 seats
Free wipe liquid
12-35ml/Car
SALES AND SERVICE NETWORK
HP231 Automatic Brushless Contactless Car Wash Machine for America/Latin America 16
Factory Show
HP231 Automatic Brushless Contactless Car Wash Machine for America/Latin America 17
HP231 Automatic Brushless Contactless Car Wash Machine for America/Latin America 18
SIMILAR PRODUCTS
HP231 Automatic Brushless Contactless Car Wash Machine for America/Latin America 19
HP231 Automatic Brushless Contactless Car Wash Machine for America/Latin America 20
HP231 Automatic Brushless Contactless Car Wash Machine for America/Latin America 21
FAQ
Q: Will we provide pre-sale services ?
A: Free product consultation is available and custom car wash solutions will be provided according to your preferences car wash machine type, daily passenger flow, venue size, etc
Q: Do you provide construction drawings design?
A: Our engineers will provide customers with a car washing plant design and construction drawings on the basis of your location, environment and purchased equipment model.

Q: How about installation?
A: We provide the installation guidance videos and human online guidance for free.

Q: What after-sales service do you provide?
A: 1) Installation support. We can assign engineers to visit the site for installation.
2) English manuals and other documents are available for delivery.
3) Lifelong technical support; maintenance service for the complete service life.
4) Warranty: one year for the whole machine.
