Name: Tunnel Car Wash System With Overall Dimensions 9500x3800x3440MM
Brand: Risense
SKU: CC-690
Price: 40 USD
Availability: InStock
Rating: 4.9 (125 reviews)

Home > products > Tunnel Car Wash Machine >

Tunnel Car Wash System With Overall Dimensions 9500x3800x3440MM

Place of Origin:

Shandong, China

Brand Name:

Risense

Model Number:

CC-690

Request A Quote

Product Details

Size:

9500x3800x3440MM

Material:

Hot-dip Galvanized Frame

Warranty:

1 Year

Output Power:

>1500W

Design Style:

New China-Chic

Automatic Type:

Fully Automatic

Overall Dimensions:

9500x3800x3440MM

Assembling Range:

11600x3800mm

Total Power:

34.82KW

Control System:

PLC

No. Of Brushes:

Nine Brushes

Blower And Dryer:

Including

Application:

Car Wash Business

Available Car To Wash:

Car/jeep/coach Within 10seats

Available Size For Car:

5300x2200x2100mm

Port:

Qingdao Port, China

Payment & Shipping Terms

Minimum Order Quantity

1 PC

Price

$40,000.00/sets >=1 sets

Packaging Details

The car wash machine will be packaged by seaworthy cases or pallets.

Supply Ability

100 Set/Sets per Month

1758038003440mm Full Automatic Express Car Wash Tunnel with 14 Brushes and Air Dryer

Get Best Price

Video

Risense CC-690 Tunnel Car Wash System Revolutionary Design 10ml/Car Shampoo Consumption

Get Best Price

Video

Risense 14 Brushes Drive Through Automatic Car Wash Tunnel with High Pressure Cleaner

Get Best Price

Video

Experience the Convenience of Our Automatic Brush Washing System for Car Tunnel Type

Get Best Price

Contact Now

Product Description

Product Overview

Risense brush wash New Arrival 14 Brushes Fully Automatic tunnel car wash equipment systems

This tunnel car wash system has 9 brushes, and will wash every aspect of a car, all while using less water and a lower power
consumption. This car wash system improves washing efficiency, saves utilities, and increases customer profits, making this conveyor car wash a popular system among our customers.

PRODUCT SPECIFICATIONS

Model	CC-690
Dimension	LWH: 9.5m3.8m3.44m
Dimension		Conveyor 11.6m(including car wheel guide devices)
Assembling Range	LW: 11880mm3800mm
Voltage	AC380V, 50Hz (5 wire system)
Water supply	DN25mm, water flow rate>200L/min
Air pressure	0.75-0.9Mpa
Air flow rate	more than 0.1m3/min
Ground flatness	Deviation less than 10mm
Applicable vehicle	Sedan, Jeep, Minibus within 10 seats
Applicable car dimension	LWH: 5.2m2.15m2.2m(wheelbase less than 3.2m)
Washing efficiency	55-60 cars/h
Small vertical brush	4
large vertical brush	4
overhead brush	1
Water consumption	95-140L/car
Power consumption	0.6kw/car
Shampoo consumption	7ml/car
Water wax consumption	12ml/car

Main Parts Display

Installation Cases

Perfect Services

Package and Delivery

Company Profile

Qingdao Risense Mechatronics Co., Ltd. is a manufacturer of Car Washing Machines with advanced production equipment and strong technical force. Our products are popular with car dealers, coach station and travel agencies because of its wide series, high quality washing effect,reasonable prices and stylish designs. Our products are extensively used in car decoration and other industries. Our products are widely recognized and trusted by users and can meet continuously developing economic and social needs. We welcome new and old customers from all walks of life to contact us for future business relationships and achieving mutual success!

As a car wash system manufacturer, we have nearly 10 years of production experience. To date, our vehicle cleaning systems have been sold in more than 100 countries including Russia, the United States, Canada, Singapore, Saudi Arabia, Pakistan, and Spain. If you are in search of a new vehicle cleaning system or are looking for an agency opportunity, you are welcome to contact us.

Our company has obtained ISO9001 Quality System Certification, Europe CE Quality Certification and ISO 14001 Environment Certification. We conduct production and quality inspections in strict accordance with the standards set by these governing bodies and some of our own additional standards. We put forth great effort to meet all of the requirements of our customers.

FAQ

Q: Will we provide pre-sale services?
A: Free product consultation is available and custom car wash solutions will be provided according to your preferences car wash machine type, daily passenger flow, venue size, etc.

Q: What are your cooperation modes?
A: There are two cooperation modes with Risense: agency and distribution. You can become an agent by purchasing more than 10 vehicle wash machines every year and as one of our distributors, you can enjoy a more favorable price.

Q: Do you provide construction drawings design?
A: Our engineers will provide customers with a car washing plant design and construction drawings on the basis of your location, environment, and purchased equipment model.

Q: How about installation?
A: Our after-sales installation engineers will go to the site and offer customers free installation, testing, operational
training, and maintenance training.

Q: What after-sales service do you provide?
A: 1) Installation support. We can assign engineers to visit the site for installation.
2) English manuals and other documents are available for delivery.
3) Lifelong technical support; maintenance service for the complete service life.
4) Warranty: one year for the whole machine.
